Solar Hybrid Inverter SAJ 5kw

MODEL: H1-5K-S2
Solar hybrid inverter is an equipment designed to combine the utility of a battery inverter and a solar inverter into one single, multipurpose device.
H1 series products are solar hybrid inverters without transformers, and the inverters are important components of energy storage systems.
The H1 inverters converts the DC generated by solar panels into AC which is in accordance with the requirements of public grid and send the AC into the grid, reduce the load pressure of the grid.
When the grid failure, provide AC source to supply important loads, achieve uninterrupted power supply function.

The Features for the 5kw hybrid solar inverter Products :

1. With UPS function switch time ≤ 10ms
2. Fan less design quiet and comfortable
3. Zero export function supported
4. Max. 100A charge current
5. 24H energy monitoring and management
6. Easy setting of smart working modes
7. with 5 years warranty and with WIFI mock

Specification:

DC Input

Max. PV Array Power [Wp]@STC 7500
MPPT Voltage Range [V] 90-550
Rated DC Voltage [V] 360
Max. DC Input Current [A] 120
No. of MPPT 2
Battery Voltage/Voltage Range [V] 48/42~58.5
Max. Charging /Discharging Current [A] 100/100

AC Output [On-grid]

Rated AC Power [W] 5000

AC Input [On-grid]

Rated AC Voltage/Range [V] L+N+PE, 220,230,240/180～280
Rated Input Frequency [Hz] 50,60
Max. Input Current [A]@230Vac 21.7

AC Output [Back-up]

Max. Output Power [VA] 5000
Max. Output Current [A] 21.8
Peak Output Apparent Power [VA] 6000, 10s
Rated AC Voltage/Range [V] L+N+PE, 220,230,240/180～280
Rated Output Frequency/Range [Hz] 50,60/45～55,55～65
Max. Efficiency 97.6%

General Parameters

Operating Temperature -25℃ – +60℃ (45℃ – 60℃ with de-rating)
Ingress Protection IP65
Dimensions [H*W*D] [mm] 470*470*190
Weight [kg] 23
Warranty [Year] 5/10/15/20
